UV VIS Spectrophotometer Single Beam | Ultraviolet Visible Spectrophotometer 190–1100nm Range, 1.8nm Bandwidth with UV/VIS Analyst Software Model MNH6000PC

Experience precise and reliable analytical performance with the UV/VIS Spectrophotometer, designed for high accuracy, stability, and user-friendly operation. Equipped with advanced optical and microcomputer technology, this single-beam spectrophotometer delivers consistent and reproducible results for a wide range of laboratory applications.

Key Features

• High Accuracy & Stability:
  The low stray light and high-resolution optical system ensure precise measurements with excellent stability and reproducibility.

• Advanced Design & Construction:
  Built on an 8mm-thick die-cast aluminum optical base, providing exceptional rigidity and durability for long-term accuracy and reliability.

• 6-Inch Color LCD Display:
  A large, high-definition screen displays all data and graphical information clearly for easier operation and analysis.

• Comprehensive Measurement Modes:
  Supports photometric, quantitative, wavelength scanning, kinetic, DNA/Protein, and multi-wavelength measurements — all available offline without PC connection.

• Powerful Data Management:
  Flexible data saving, retrieval, and graph zooming. Data stored in the instrument memory can be easily exported to a PC via USB for further analysis.

• Enhanced Functionality:
  Compatible with automatic cell holders for precise cell position control and smooth workflow.

• Integrated Technology:
  Combines optics, electronics, and microcomputer systems with a scientifically optimized design for superior operational performance.

Technical Specifications

• Wavelength Range: 190–1100nm

• Bandwidth: 1.8nm

• Wavelength Accuracy: ±0.5nm

• Wavelength Repeatability: ≤0.2nm

• Photometric Accuracy: ±0.3%T (0–100%T)

• Photometric Repeatability: ≤0.1%T

• Photometric Range: -0.3–3A, 0–200%T, 0–9999C

• Stability: ≤0.001A/30min @ 500nm

• Stray Light: ≤0.05%T @ 220nm & 360nm

• Output Interface: USB Port & Parallel Port

• Display: 320×240 Dots Color LCD

• Light Source: Deuterium Lamp & Tungsten Lamp

• Detector: Silicon Photodiode

• Power Requirements: AC 110/220V, 50/60Hz

• Dimensions: 470 × 400 × 220mm

• Packing Size & Weight: 620 × 530 × 370mm, 44LBS

Functions of the UV/VIS Analyst Software

1. Main Functions: Single wavelength photometric measurement, Fixed Points Measurement, Concentration Measurement, Wavelength Scanning, Time Scanning, DNA/Protein Measurement.
2. Spectrum Processing Function: Trace a Spectrum, Automatic Peak Detection, Scale Expansion, Differentiation, Calculate Spectrum
3. System Check and Calibration Function: Instrument Validity Check, Dark Current Check, Spectrum Slitwidth Check, Energy of Light Sources Check, Reset Wavelength

This UV/VIS Spectrophotometer is ideal for research laboratories, environmental monitoring, chemical analysis, and biological testing, offering high precision, ease of use, and powerful analytical capabilities.
