1.Big-screen LCD, film-style keypad, can display real-time sampling date and time (year, month, date, minute, second), low-voltage
warning, automatic shutdown.
2.GLZ-B model adopt RS232 interface, extract datum and import EXCEL for graphics, analysis software for free download and upgrade by computer.
3.Special suitcase, smart and convenient to operate in field.
Hardness Portable Photons Tester I Testing Instrument & Equipment I Meubon
by meubon
Save 32%
Original price
$1,620.00
Original price
$1,620.00
-
Original price
$1,620.00
Original price
$1,620.00
Current price
$1,100.00
$1,100.00
-
$1,100.00
Current price
$1,100.00
Characteristics
Model |
Function Difference |
GLZ-A |
Without computer interface, can only store datum to the main controller |
GLZ-B |
Communication interface: RS485 single- channel, with computer interface, can not only store datum to the main controller, but also import datum to the computer for processing |
GLZ-C |
Communication interface: RS-485 double-channel, with computer interface, can record two parameters---PAR and illuminance, can not only store datum to the main controller, but also import datum to the computer for processing. |
Features
1.In plant growth and development process, the radiation factor plays an important role.
2.First of all radiation is the energy of plant photosynthesis, the process of photosynthesis influence the formation of
production and product quality.
3.Secondly, as a regulation of the energy, it will play an important role to the development of plants morphology, leaves shape.
and size as well as from vegetative growth to reproductive growth rate changes.
4.Photons meter mainly used for agriculture, forestry and other research and production departments for PAR radiation measurement.
Its characteristics are the spectral response simulation probe photosynthetic function effectively, digital show, portable
compact, with good accuracy and stability.
2.First of all radiation is the energy of plant photosynthesis, the process of photosynthesis influence the formation of
production and product quality.
3.Secondly, as a regulation of the energy, it will play an important role to the development of plants morphology, leaves shape.
and size as well as from vegetative growth to reproductive growth rate changes.
4.Photons meter mainly used for agriculture, forestry and other research and production departments for PAR radiation measurement.
Its characteristics are the spectral response simulation probe photosynthetic function effectively, digital show, portable
compact, with good accuracy and stability.
Specification
Technical parameter |
||||||
Testing Index |
Parameter |
|||||
Temperature |
Range:-40℃ - 120℃; Accuracy:±0.3℃; Resolution:0.1℃ |
|||||
Humidity |
Range:0-100%RH; Accuracy:±3%RH; Resolution: 0.1%RH |
|||||
Dew Point |
Range:-40℃ - 120℃; Accuracy:±0.4℃; Resolution:0.1℃ |
|||||
Soil Salinity |
Range: 0-23mS/cm; Accuracy: ±2%FS; Resolution: 0.01mS/cm |
|||||
Soil compaction |
Range: 0-89kg/cm² (0-100kg)/(0-7922kpa)/(0-890N/cm²); Accuracy: ±0.5%; Resolution: 1 |
|||||
Dew point |
Range: -40℃~120℃; Resolution: 0.1℃; Accuracy: ±0.4℃ |
|||||
Light intensity |
Range: 0~200000Lux; Resolution: 1Lux; Accuracy: ±2%FS |
|||||
Photosynthetically active radiation |
range: 0~2700umol/m s; Resolution: 1μmol/m² s; Accuracy: ±1μmol/m² s |
|||||
Wind direction |
Range: 0~360°; Accuracy: ±5°; Resolution: 3° |
|||||
Wind speed |
Range: Wind speed 0~45m/s; Resolution: 0.1m/s; Accuracy: Wind speed ±(0.5+0.03xV)m/s |
|||||
Rainfall |
Range: 0~4mm/min; Accuracy: ±0.1mm; Resolution: 0.1mm |
|||||
CO₂ concentration |
Range: 0~2000PPM (if you want a range of 5000PPM or above, please notify before ordering); Accuracy: ±(50PPM +measured value x3%); Resolution: 1PPM |
|||||
Soil temperature |
Range: -50℃~100℃; Accuracy: ±0.5℃; Resolution: 0.1℃ |
|||||
Soil moisture |
Range: 0~100%; Resolution: 0.1%; Accuracy: ±2.5% (indoor) ±5% (outdoor) |
|||||
pH |
Range: 0~14; Accuracy: ±0.5 |
|||||
Total radiation |
Range: 0~2000w/m²; Accuracy: ±1% (daily accumulation); Resolution: 5W/m² |
|||||
