Precision Controlled Environmental Chamber: Programmable with Temperature and Humidity Regulation I Benchtop Environmental Climate Test Chamber

Explore the Versatile Temperature Humidity Test Chamber, Ideal for Assessing Material Endurance

This temperature humidity test chamber is a crucial tool for evaluating the heat, cold, dry, and humidity resistance of various materials. It finds application across a wide spectrum of industries including electronics, electrical appliances, communications, instrumentation, vehicles, plastics, metals, food, chemicals, building materials, medical, aerospace, and more.

We have 80L,150L,225L,408L,800L,1000L for you to choose. We have temperature levels:-20~+150;-40~+150;-70~+150,The humidity test range could do from 20%-98%.

Please contact customer service concerning the max heating load and any other test requirement you have.

Key Specifications:

• Inner Size (WHD): 405040 cm
• External Size (WHD): 60161.5120.5 cm
• Window Size (WH): 400*500 mm
• Test Hole Size: 2 holes, 50mm each
• Weight: 225KG
• Voltage: 1Ø 220V 50Hz/ 3Ø 380V 60Hz/ Customized
• Temperature Range: -70℃ ～180℃
• Humidity Range: 10% ～98%RH (5%~98% R.H. customized)
• Temp.& Humidity Control Fluctuation: ≤±0.5℃, ≤ ±2.5%RH
• Indication Resolution: 0.01℃, 0.1 %RH
• Temp.& Humidity Uniformity: ≤±1.5℃, ≤±2.5% RH
• Heat Up & Cool Down Time: ≤5℃/min for heating; ≤ 1.2℃/min for cooling
• Cooling Type: Air cold
• Chamber Materials: SUS#304 stainless steel for Inner chamber with thickness 1.5mm; Steel plate for external chamber with thickness 1.5mm
• Insulation Materials: Rigid polyurethane foam + ultrafine glass fiber with thickness of 100mm

Mechanical Room Includes:

• Refrigerating unit
• Water supply and drainage device
• Blower fan
• Power distributing cabinet
• Humidifying and humidity measuring water utilization control device

Electronic Box Features:

• Heat emission blower fan
• Distribution switchboard
• Test terminal of sample
• USB physical interface (need to be purchased together with centralized monitoring software)
• Residual current circuit breaker of main power supply

Heating Device:

• Basin heating humidifying method
• Stainless steel armored heater is adopted in basin humidification
• Control mode of heater: non-contact equal period pulse-width modulation, SSR (solid state relay)
• Water level control device, dry heating prevention device of heater

Humidifier:

• Basin heating humidifying method
• Control mode of heater: non-contact equal period pulse-width modulation, SSR (solid state relay)
• Water level control device, dry heating prevention device of heater

Control Panel Highlights:

• Temperature (humidity) control display
• Over-temperature protection setting device
• Emergency switch
• Run indicator
• Failure indicator

Compressor:

• Imported compressor
• Fits wide range of pressure
• Higher heating efficiency
• Easy to maintain

Features:

1. Unique design of the box within the wind circulation structure ensures uniformity within ± 2 ℃ under test conditions.
2. Anti-drip design at the top of the box during humidity tests prevents water short circuits and surface water pollution.
3. Incorporates the latest environmentally friendly adsorption drying processor to effectively control surface temperature condensation.
4. The fully sealed and soundproofed refrigeration room reduces machine noise and box resonance, keeping machine noise controlled within 75db.

• Warranty : 14 months, 12month spare parts replacement for free
• Product name : Benchtop Environmental Climate Temperature Humidity Test Chamber
• Body Materials : SUS#304 Stainless Steel Plate
• Compressor : Original France Tecumseh
• Refrigerant : Environmental friendly R23/R404A
• Controller : Programmable LCD Touch Screen
• Casters : Easy mobility and safe
• Water Level : Visible
• Waterway device and circuit devices : Separated
• Cable Port : External Power
