QUV Degradation Tester for UV Irradiation Testing in Lab Aging Chamber I Model MBZL6008

Experience Advanced Testing Capabilities with Our QUV Degradation Tester UV Irradiation Testing Machine.

Our UV Lamp Lab Aging Testing Chamber simulates the damaging effects of sunlight, rain, and dew on materials. Utilizing UV lamps, it mimics sunlight exposure, cold rain, and dew conditions. Materials undergo testing in an environment with alternating light and moisture over several days or weeks, revealing potential damage akin to outdoor exposure over months or years. Damage types include bleaching, discoloration, loss of light, powdering, cracking, turbidity, bubble formation, embrittlement, strength decline, and oxidation.

Standards Compliance: ASTM G53-77, GB, GJB, MIL, ASTM, CNS, IEC, JIS, AATCC, DIN, Fed Test, BS, SAE, ASTM D4355, ISO-4892, ASTM-G53, D4587, 4799, BS-27282, SAE-J2020

Applicable Industries: Ideal for use in paint, resins, plastics, printing and packaging, aluminum, adhesives, automotive, cosmetics, metals, electronics, electroplating, and more.

Technical Parameters:

• Model: MZL6008 QUV UV Aging Testing Machine
• Temperature Range: RT+10℃~70℃
• Temperature Uniformity: ±3℃; Temperature Fluctuation: ±0.5℃
• Humidity Range: ≥75%RH
• Ultraviolet Tube: UVA-340 (Wavelength Range: 290-400nm); UVB-313 (Wavelength Range: 280-320nm)
• Standard Test Piece: 75×150mm/21 pieces
• Irradiation Intensity: 0.30-1.1W/m2 (Adjustable)
• Compliant with Standards: GB/T 14522-93, ASTM G 154, ISO 4892-1, ISO 11507, ASTM D 4329

Applications:

• Simulates sunlight, humidity, and temperature effects on materials
• Identifies aging effects like fading, gloss loss, strength reduction, cracking, peeling, chalking, and oxidation
• Reproduces outdoor damage in a controlled lab environment
• Suitable for various industries including paint coatings, automotive, plastics, wood products, adhesives, and anodic oxide film.

Enhance your testing capabilities with our QUV Degradation Tester UV Irradiation Testing Machine.

• Warranty : 2 years, 24 monthes
• Model Number : MBZL6008
• Power : Electronic
• Name : Lab Programmable Light Accelerated Aging UV Test Chamber
• Radiometer : option
• Recorder : option
• Water and consumption : distilled water, 8 liters / day
• UV temperature : From 50 ℃ to 75 ℃
• Testing capacity : 48 piece(75 x 150m m ) / 50 piece( 75 x 150m m )
• Power supply : 120V/60Hz,16A or 230V/50Hz, 9A,1800W(max)
• Volatility / uniformly : ±0.1℃;±0.1%R.H./ ±1.0℃;±3.0%R.H.
• Weight : 300lbs
