XRF Gold Purity Tester Machine I High Precision Precious Metal Gold Karat silver Platinum and Palladium Analyzer I Jewelry Tester

Function:

• Tests all colors of gold from 1% to 99.99% and silver, platinum and palladium
• Hand-tough display shows both karat value and all percentages do metals
• Easy one-step calibration using pure silver
• Easy and safe to operate it(don’t need any professional person)
• All data could be stored in the computer
• Reports can be printed out with A4/A5 and label form
• Follow easy steps to identify non-gold and plated gold

Can be used by : Jewelry Shops, Jewelry Manufacturers, Precious Metal Refineries, Pawn shops, Banks, Laboratories, Universities, Quality Inspection bureaus and basically any place that deals with gold or precious metals.

The new advanced gold XRF testing machine is the ultimate verification instrument for gold,silver, platinum and palladium testing. This state-of-the-art tester has exceptional precision and nondestructive .It is simple to use and in seconds provides accurate results showing both the digital karat value and percentages of all metals in the sample.



This gold tester is integrated an industrial computer with industrial motherboard & multi-point hand touch. Providing best operation experience. It is designed exactly to security standards with active radiation protection, high voltage protection and X-ray tube overheating protection.Warm-up and anti interference procedure is controlled by the program, to reduce the interference by the reflected X-ray and the spectrums, to add the accuracy and stability. Optional colors for different elements will help to distinguish the interested elements clearly and conveniently. When the testing is over, the testing report will be shown timely.

Benefits





High speed and accuracy Intuitive interface Autonomous operation as well as connected to a PC Compact, doesn’t take much space on a desk or a counter Ergonomic design looks very nice in a jewelry shop Customer display – Chemical composition can be seen by customer during measurement Radiation protection High Voltage protection X-ray Tube overheating protection                                Inbuilt industrial motherboard & multi-point hand touch FCC,CE ,RoHS approved Tests jewelry and metal samples of any size,shape or weight

X-ray fluorescence analysis surpasses the rest of analytical methods in terms of speed, accuracy, and simplicity. It’s a non-destructive method, in which analysis is targeted at the spot of interest. The diameter of an analytical spot can be easily changed.



 Who can use this machine?

Jewelry Shops, Jewelry Manufacturers, Precious Metal Refineries, Pawn shops, Banks, Laboratories, Universities, Quality Inspection bureaus and basically any place that deals with gold or precious metals.



Specifications:

Working Principle:	Energy Dispersive X-ray Fluorescence
Size(mm):	670*400*330
Detection limit:	100ppm Best substance effect
Precision:	±10ppm~0.2%
Expanded Uncertainty:	≤0.36%
Operating Environment:	Temperature 0-28℃
	Humidity ≤70%
High Voltage:	0~50KV/0~1MA
Detector:	Gas Proportional Detector
Testable Elements:	Au, Ag, Cu,  Pt, Pd, Ir,Cd,ect.
Hardware:	Integrated PC with touch screen, Wireless LAN, USB interfaces, HD camera
Main Structure:	High-strength metal frame and industry plastic shell
N/G Weight:	368/90lbs
